5 Miracle Water Installation & Operation Manual
Miscellaneous Service Information
DESIGN SPECIFICATION MW-30
FILL CYCLE < FLOW .3 gpm
BRINE CYCLE = FLOW .22 gpm
BRINE RINSE CYCLE = FLOW .15 gpm
BACKWASH CYCLE (MAX.) = FLOW 2.0 gpm
FAST RINSE CYCLE (MAX.) = FLOW 2.0 gpm
< gallon per minute flow to brine tank
= gallon per minute flow to drain
Salt Storage Capacity
MW-30 - 150 lbs.
Product Specifications
MW-30
Rated Service Flow Rate (gpm) 8.0
Amount of High Capacity Resin (cu ft) .82
Pressure Drop at Rated Service Flow (psig) 12
Water Supply Max. Hardness (gpg) 95
Water Supply Max. Clear Water Iron (ppm)* 5
Water Pressure Limits (min./max. psi) 20 - 125
Min. - Max. Water Temperature ( o F) 40 - 120
Min. Water Supply Flow Rate (gpm) 3
Max. Drain Flow Rate (gpm) 2.2
* State of Wisconsin requires additional treatment if water supply contains
greater than 5 ppm clear water iron.
Performance Claims
MW-30
Rated Softening Capacity (Grains @ 14,700 @ 2.9
Pound Salt Dose) 25,400 @ 8.0
30,100 @ 13.1
Rated Efficiency (Grains/Pound of
5060 @ 2.9 lbs.
Salt @ Minimum Salt Dose
This system conform to NSF/ANSI 44 for the specific performance claims as
verified and substantiated by test data.
The efficiency rating is only valid at the minimum stated salt dose. This sof-
tener is efficiency rated according to NSF/ANSI Standard 44.
