Features:
• Swing–out horizontal rotor design (patent-pending), incorporating a
unique test tube holder that produces horizontally separated samples
while requiring no additional parts
• Digital time display for easy time setting and verification
• Cool–Flow air flow design that prevents overheating of samples
• Heavy gauge steel construction for safety and durability
• Lid safety switch that prevents the centrifuge from operating unless the
lid is closed and latched
• Removable rotor for easy cleaning
• Locking lid that allows entry into the centrifuge only after the rotor has
completely stopped
• Brushless permanent split capacitor AC motor
• Clear lid for safe observation of samples and optical calibration of speed
• Electonic braking for reduced deceleration time
• Push-button operation
• Indicator lights:
‘RUN’ green –lights when power is applied to the motor
‘LATCH’ yellow –lights when the lid is closed and latched
‘UNLOCKED’ red –lights when the lock system is deactivated
Page 3
Specifications:
General Specifications for the Horizon Centrifuge
Nominal Speed: 3,150 (+/- 150) RPM
Nominal RCF: 1500 (+/- 100) xg
Maximum capacity: 120 mL (12 x 10 mL)*
Overall Dimensions (H x W x D): 9.0 in. x 12.5 in. x 15 in.
Centrifuge Motor: 1/30 HP, p.s.c. motor
Nominal Acceleration Time: 60 seconds
Protection Breaker: 4 Amp. re–settable
Timer: electronic, 1 to 99 minutes
+/– 1%
Current Requirement: 1.46 Amps
Voltage Requirement: 115 (+/- 10) Volts
Frequency: 60 Hz
Weight: 18.5 lbs.
Any use other than those specified by the Manufacturer is explicitly prohibited.
* Maximum sample density is 1.15 grams / mL, (water density = 1.0 grams / mL)
Page 10
1. Problem: The rotor does not spin freely.
Solutions: – Make sure nothing has fallen into the rotor chamber.
– If there is nothing obstructing the rotor, contact The Drucker
Company for further assistance.
2. Problem: Excessive noise when the machine is running.
Solutions: – Check to see that the load is balanced.
– Make sure that nothing has fallen into the rotor chamber.
– Make sure that the nut in the center of the rotor is tight.
– Have a technician test the motor and replace it if necessary.
3. Problem: The centrifuge does not run.
Solutions: – Check the electrical outlet.
– Make sure the lid latch is turned completely clockwise to its stop
position. When the lid is closed properly, the latch light on
the control panel will illuminate.
– Check the circuit breaker switch at the bottom left of the machine.
If the switch is white, the breaker has tripped. Contact The
Drucker Company for further assistance.
– The printed circuit board may be damaged. Have a technician test
and replace the circuit board if necessary.
4. Problem: The latch light does not come on when the lid is closed
Solutions: – Make sure that the unit has power.
– Make sure the lid latch is turned completely clockwise to its stop
position. The latch makes contact with a switch underneath the
front top of the cabinet. If this switch is not activated, the light will
not turn on and the machine will not run.
5. Problem: The machine does not unlock after a run has completed or will not
unlock when the OPEN / EMERGENCY STOP button is pressed.
Solutions: The lid can only be unlocked when the rotor is at rest. The lid is un-
locked when the red UNLOCKED indicator light is illuminated.
– The lid should remained locked until the rotor has nearly come to a
complete stop and then unlock for 60 seconds. If additional unlock
time is needed, press the ’OPEN / EMERGENCY STOP’ button with
the machine plugged in and the rotor stopped. If the lid remains
locked after this and will not unlock, the electronics may have been
damaged. Contact The Drucker Company for assistance. To
access the rotor chamber, follow the procedure on page 11,
“Emergency Lid Removal”.
Troubleshooting:
NOTE:
The latch must be turned
completely clockwise to its
stop position in order for the
centrifuge to operate.
For servicing information or additional technical support, contact The
Drucker Company at 814-342-6205 or 814-692-7661 .
