1. Cradle bar - Supports the bird cradle.
2. Launcher box - Frames the launcher and
contains large holes for maximum air flow
and scenting possibilities.
3. Solenoid - Activates the latch.
4. Latch - Holds the bird cradle closed when it is
set for launch.
5. Safety pin - When inserted, roller bearing
prevents the bird launcher from being
opened.
6. Release lever - Is held closed by the latch
when the launcher is set.
7. Bird cradle - Holds dummy or birds for
launching.
LAUNCHER FUNCTIONS : LAUNCHER SIZE
SIZE : (Launcher) - for quail
- 8.6 4.5 4.3
- an excellent choice for quail and pigeons
(Launcher)- for pheasant
- 13.2 6.9 6.9
- handles large birds with ease
