Description of transmitter parts – Dogtra 1600 Series User Manual
Page 5
6
TRANSMITTER
7
TRANSMITTER
Transmitter Antenna
A short 2 antenna is supplied with the
transmitter.
The antenna should be screwed into the top
of the transmitter to ensure that the signals are
sent properly to the collar receiver and that
maximum range is attained.
2 Antenna
DESCRIPTION OF
TRANSMITTER PARTS
transmitter
2
Antenna
Indicator
Light
“Nick” Button
*
Selector or
Toggle Switch
“Constant” Button
“Pager” Button
Intensity
Selection Dial
indicates optional switch for 2-dog models
