19
BATTERY CHARGER
18
COLLAR / RECEIVER
The battery charger and charging cables
allow you to charge both the transmitter and
receiver at the same time. The battery charger is
designed for a 120 volt wall outlet. (European
230 volt AC chargers and 12-volt field charger
for your automobile are also available.)
To use the battery charger for the two-dog
unit, combine both sets of battery charging
(splitter) cables as shown. This enables you to
charge the transmitter and both receivers at the
same time.
BATTERY CHARGER
Charging Cable
120 volt
Charger
Wall Outlet Two-dog unit only
Receiver Battery Charging Receptacle
On the inside of the collar, next to the collar
strap, is a battery charging receptacle with a
rubber cover plug.
Internal Antenna
The has a non-exposed
antenna that is located inside the collar receiver.
Receiver
Charging
Receptacle
