DESCRIPTION OF TRANSMITTER PARTS
DESCRIPTION OF
TRANSMITTER PARTS
7
DESCRIPTION OF TRANSMITTER PARTS
transmitter
Antenna
Nick/Constant
toggle switch
On/off magnetic
red dot
Rubber-charging
cap
1
st
-dog
pager
(gray button)
2
nd
-dog
Pager
(orange button)
On/off
and
mode
button
LCD screen
Rheostat
intensity dial
LED indicator
1
st
-dog
Nick & Constant
(gray button)
2
nd
-dog
Nick & Constant
(orange button)
Metal belt
clip
Transmitter Antenna
A 2” antenna is supplied with the
transmitter.
The antenna must be fastened to the transmitter before
using the unit.
Rheostat Intensity Dial
The rheostat intensity dial, on the top of the
transmitter, controls the stimulation level, with level
1 being the lowest level and level 127 being the
highest. The LCD screen shows the intensity level
during operation.
