DESCRIPTION OF TRANSMITTER PARTS
Transmitter Antenna
A heavy-duty 3.2 antenna is supplied with
the transmitter.
The antenna should be screwed into the top of
the transmitter to ensure that the signals are sent
properly to the collar receiver and that maximum
range is attained.
3.2 Antenna
7
DESCRIPTION OF TRANSMITTER PARTS
DESCRIPTION OF
TRANSMITTER PARTS
transmitter
Antenna
1 st -dog button
3 rd -dog button
4 th -dog button
Intensity
selection dial
Indicator light
Selector or
toggle switch
(Nick, constant)
2 nd -dog button
indicates optional switch for 4-dog models
