3.2 Camera tilt
The camera tilt angle is adjustable + / - 20 degrees by the mechanical mounting in a software-
controlled tilting unit.
3.2.1 Tilt up
In “CAM mode”, press "Up”-button repeatedly to adjust the camera view angle upwards.
The camera will tilt upward in steps until the end position is reached, the tilt indicator will follow
the camera movement.
Press the button repeatedly until the proper view angle is achieved, the setting is saved as
default and in the event of power failure, the camera will go directly to this position.
Horizon
Top
