Palm Rest
Dell™ Latitude™ D620 Service Manual
1.
Follow the instructions in
Before Working Inside Your Computer
.
2.
Remove the hinge cover (see
Hinge Cover
).
3.
Remove any devices installed in the media bay (see
Media Bay Devices
).
4.
Remove the keyboard (see
Keyboard
).
5.
Remove the display assembly (see
Display Assembly
).
6.
Remove the internal card with Bluetooth® wireless technology (see
Internal Card with Bluetooth® Wireless Technology
).
7.
Remove the coin-cell battery (see
Coin-Cell Battery
).
8.
Remove the three screws labeled "P" from the top of the palm rest.
9.
Turn the computer upside-down.
10.
Remove the hard drive (see
Hard Drive
).
11.
Loosen the two captive screws located at the front of the hard drive bay.
12.
Remove the seven M2.5 x 8-mm screws from the bottom of the computer.
CAUTION:
Before performing the following procedures, follow the safety instructions in the Product Information Guide.
CAUTION:
To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
