Series 3 Digital Force Gauges
User’s Guide
20
12.3 Capacity, Resolution & Load Cell Deflection
12.4 Dimensions
IN [MM]
Thread
Hex
M3-012
– M3-100
#10-32 UNF
5/16 [7.94]
M3-200
– M3-500
5/16-18 UNC
11/32 [8.74]
Model
Capacity
Resolution
Load Cell
Deflection
in [mm]
lbF
kgF
gF
N
lbF
kgF
gF
N
M3-012
0.12
50
0.5
0.0001
0.05
0.0005
0.005 [0.13]
M3-025
0.25
100
1
0.0002
0.1
0.001
0.010 [0.25]
M3-05
0.5
250
2.5
0.0005
0.2
0.002
0.010 [0.25]
M3-2
2
1
10
0.002
0.001
0.01
0.010 [0.25]
M3-5
5
2.5
25
0.005
0.002
0.02
0.010 [0.25]
M3-10
10
5
50
0.01
0.005
0.05
0.010 [0.25]
M3-20
20
10
100
0.02
0.01
0.1
0.010 [0.25]
M3-50
50
25
250
0.05
0.02
0.2
0.010 [0.25]
M3-100
100
50
500
0.1
0.05
0.5
0.010 [0.25]
M3-200
200
100
1000
0.2
0.1
1
0.010 [0.25]
M3-500
500
250
2500
0.5
0.2
2
0.010 [0.25]
