Typical Performance
±VCCP = ±25V
±Vcc = ±5V
Po
= 0W
BW = 22Hz~ 22kHz
0dBr = 17V
R
L
= 4 Ω
±VCCP = ±25V
±Vcc = ±5V
BW
= 22Hz~ 22kHz
0dBr = 17V
±VCCP = ±25V
±Vcc = ±5V
AES 17FILTER
THD+N < 10%
R
L
= 4Ω
R
L
= 8Ω
Po = 10W, RL = 4 Ω
Po = 5W, RL = 8 Ω
±VCCP = ±25V
±Vcc
= ±5V
Po = 0W
BW
= 22Hz~22kHz
R
L
= 4 Ω
PSRR -
PSRR +
