28

Q

UICK GUIDE

Quick Guide

Banana Plugs

Anode Banana Plug

(Red)

Notch on

U-Shaped Gasket

Gel Sandwich

Pressure Plate

Cams

Mini Tank

Inner
Chamber
Assembly

Clamping
Frame

Electrode
Assembly

Cathode Banana Plug
(Black)

Lid

Fig. 4. Assembling the Mini-PROTEAN 3 cell.
