System Overview
Introduction
The B&G V90 VHF radio is a comprehensive solution for marine VHF
radio applications.
The radio comprises:
• V90 VHF transceiver
• One wired handset as standard, and optionally up to 3 more
wired handsets. (Maximum of 4 wired handsets in total)
• One external speaker, and optionally up to 3 more external
speakers
• Up to 2 optional wireless handsets
In addition to routine ship-to-ship or ship-to-shore VHF
communications, the V90 has many advanced features, including
NMEA 2000 and NMEA 0183 network connectivity, which allows the
radio to share information with other onboard devices, such as a
GPS antenna, a chartplotter or a multi-function display.
For detailed features and specifications, see the Appendices in B&G
V90 Marine VHF radio Operating Manual.
System diagram legend
1 V90 VHF radio transceiver
2 12 VDC power supply
3 H50 wireless handset
4 H90 wired handset
5 External loudspeaker
6 NMEA 0183 GPS and horn button
7 AIS Data Output
8 Loud hailer speaker
9 VHF antenna with PL259 connector
10 NMEA 2000 network connection
