Tools required for installation, Parts – Chief Manufacturing Universal Slat Wall Multi Arm Mount KSY220 User Manual
Page 4
KSY220
Installation Instructions
4
TOOLS REQUIRED FOR INSTALLATION
J (2)
A (1)
B (1)
C (1)
#8-32 X 3/8"
D (1)
E (1)
.320 x .563 x .018"
G (4)
K (4)
1/8"
5/32"
H (2)
F (1)
L (2)
N (2)
5/16-18
P (2)
.500 x .194 x .375
3/16"
Q1 (4)
Q2 (4)
Q3 (4)
Q4 (4)
Q5 (4)
M4 X 12mm
M4 x 20mm
M4 x 30mm
.500 x .194 x .750
Q (2)
M (2)
UHMW
J (2)
(Provided)
3/16"
(Provided)
5/32"
(Provided)
1/8"
PARTS
