Amico TTS Vertical Flat Wall - Manual (Page 17)

Air Compressor Maintenance Checklist Monthly Yearly 3 months 6 months
1 Drain the water collected in the moisture trap: (the
operations are to be done with the tank under pressure).
2
Remove the condensate that has collected in the air compressor tank.
To empty the tank, put it under pressure, take the compressor
to a place where the water will not damage the floor, tip the
compressor slightly forward and open the moisture trap
bleed valve.
3
Check the compressor efficiency: possible connectors
slackening, pressure hose wear, screws tightening electric
circuit efficiency, etc.
4 Clean the compressor with a soft cloth. Dust and dirt prevent
the compressor from cooling.
5 Oil level check
6 Check the air compressor bleed valve by pulling the ring
gently when there is pressure in the tank.
7 Check the moisture trap. Replace it if its necessary.
8
Disassemble the coalescing cartridge contained in the moisture
trap. This operation must be done with the tank completely
out of pressure.
www.amico.com 17
ATTENTION: Maintenance of the compressor per the checklist is mandatory. Failure to do so will result in undue
wear and eventual malfunction, which in turn voids warranty.
