Amico Valve Alarm Combo Unit - Manual (Page 21)

Model Numbers
Alarm Valve Combo Unit
Notes:
• The power supply shall be located on the left side of the assembly.
• Valves are to be assembled vertically, with medical gas flow direction from the bottom to the top.
• The 2-1/2" and 3" valve assemblies are only offered as singles.
AVCHLN-XXGXXGXXGXXGXXGXXGXXG
Replace “XX” with the
valve size required:
1/2" = 05
3/4" = 07
1" = 10
1-1/4" = 12
1-1/2" = 15
2" = 20F
2-1/2" = 25
3" = 30
The “L” defines
the language:
U = English (NFPA)
E = English (CSA)
S = Spanish
F = French The “N” defines
the # of valves:
1 = 1 Valve
2 = 2 Valves
3 = 3 Valves
4 = 4 Valves
5 = 5 Valves
6 = 6 Valves
The “G” defines the gas
O = Oxygen
A = Medical Air
V = MedVac
2 = Nitrous Oxide
N = Nitrogen
C = Carbon Dioxide
W/E = WAGD/AGSS
I = Instrument Air Horizontal
www.amico.com 21
