ADS PrimeLog User Manual
20
velocities. A mean factor also is calculated from these values. While this
factor offers convenience, it also introduces some level of error.
Logger Configuration
After selecting the Quadrina Insertion Probe option from the PrimeWorks
flow meter menu, the following information must be provided:
 Probeflo (default) or Miniprobe
 Unidirectional (default) or bi-directional
 Standard (0.5-inch) or oversize (0.75-inch) insertion tube
 Pipe diameter
 MEP or QEP electronic interface
Selecting the MEP interface requires a choice of either single-point or multi-
point calibration. Multi-point calibration involves entering the given values or
rate (feet per second) and corresponding output frequencies (Hz) from the
calibration certificate.
For both interfaces, single-point calibration simply requires entering the value
displayed on the calibration certificate.
PrimeWorks automatically sets up the logger to calculate the flow rate in
gallons per second.
Note: Quadrina devices must be configured using PrimeWorks.
