Great Plains 2020P Assembly Instructions User Manual
Page 7
113-688M
3/3/2006
Great Plains Mfg., Inc.
7
Installation Instructions
113-691A MARKER, 3PT 15-P SINGLE LH
Your kit includes:
1
811-017C
HH1/4R1 156 3/8MNPT 1/2MNP
1
811-300C
HH1/4R1 176 3/8MNPT 1/2MNP
1
113-180H
LH FIRST SECTION
1
113-191H
2 SECTION MARKER BREAKAWAY
1
113-248D
PIN 1 OD X 4.34 USABLE
1
113-312D
FIRST PIVOT SHAFT
1
113-313D
SECOND PIVOT SHAFT
1
113-324D
CYLINDER STOP
2
113-325D
STOP BUSHING
1
113-351D
MARKER TUBE 42 LG
1
113-468H
LIFT LUG CHANNEL L.H.
2
113-491D
ADJUST MOUNT SPACER TUBE
1
113-503H
MARKER DISK ADJUST MOUNT
1
113-563S
MARKER DISC & HUB ASSEMBLY
1
113-689H
MARKER MOUNT LH
2
800-001C
GREASE ZERK STRAIGHT 1/4-28
2
801-054C
SCREW SET SQ HD 1/2-13X1 GR5
4
802-099C
HHCS 1/2-13X3 1/4 GR5
2
802-115C
HHCS 5/16-18X2 GR5
1
802-249C
HHCS 1/2-13X4 1/2 GR5 SPTHD
1
802-253C
HHCS 3/8-16X1 3/4 GR2
1
802-254C
HHCS 5/8-11X5 1/2 GR5
2
803-011C
NUT LOCK 5/16-18 PLT
1
803-013C
NUT LOCK 3/8-16 PLT
1
803-019C
NUT LOCK 1/2-13 PLT
4
803-020C
NUT HEX 1/2-13 PLT
1
803-024C
NUT LOCK 5/8-11 PLT
2
803-036C
NUT HEX JAM 1/2-13 PLT
4
804-015C
WASHER LOCK SPRING 1/2 PLT
4
804-017C
WASHER FLAT 1/2 USS PLT
2
804-029C
WASHER FLAT 1 SAE
2
805-058C
PIN COTTER 3/16 X 2
1
810-205C
CYL 2X20X1.12 ROD (TIE) 1
1
818-229C
DECAL AMBER REFLECTOR
2
818-682C
DECAL WARNING PINCH/CRUSH MRKR
2
803-020C
NUT HEX 1/2-13 PLT
4
803-021C
NUT HEX 5/8-11 PLT
2
804-015C
WASHER LOCK SPRING 1/2 PLT
4
804-021C
WASHER FLAT 5/8 SAE PLT
4
804-022C
WASHER LOCK SPRING 5/8 PLT
2
806-053C
U-BOLT 5/8-11 X 7 1/32 X 6 1/2
1
806-122C
U-BOLT 1/2-13 X 3 1/32 X 6
1
810-058C
VALVE 3/8 NEEDLE
1
811-044C
AD 3/8MNPT
2
811-281C
EL 3/8FNPT 9/16MORB
Qty.
Part No.
Part Description
