Great Plains 2020P Assembly Instructions User Manual
Page 10
3/3/2006
113-688M
Great Plains Mfg., Inc.
Marker Option
10
113-694A MARKER, 3PT 20-P DUAL
Your kit includes:
2
811-015C
HH1/4R1 192 3/8MNPT 1/2MNPT
2
811-297C
SP HH1/4R1 212 3/8MNPT-W/AD
1
113-597V
20’ DUAL FF HOSE BUNDLE
1
113-180H
LH FIRST SECTION
1
113-188H
RH FIRST SECTION
2
113-248D
PIN 1 OD X 4.34 USABLE
2
113-312D
FIRST PIVOT SHAFT
2
113-313D
SECOND PIVOT SHAFT
2
113-324D
CYLINDER STOP
4
113-325D
STOP BUSHING
2
113-354D
13’ MARKER TUBE 46 1/2 LONG
1
113-467H
LIFT LUG CHANNEL R.H.
1
113-468H
LIFT LUG CHANNEL L.H.
4
113-491D
ADJUST MOUNT SPACER TUBE
2
113-503H
MARKER DISK ADJUST MOUNT
2
113-563S
MARKER DISC & HUB ASSEMBLY
2
113-646H
20’ MARKER BREAKAWAY
1
113-689H
MARKER MOUNT LH
1
113-690H
MARKER MOUNT RH
4
800-001C
GREASE ZERK STRAIGHT 1/4-28
4
801-054C
SCREW SET SQ HD 1/2-13X1 GR5
8
802-099C
HHCS 1/2-13X3 1/4 GR5
4
802-115C
HHCS 5/16-18X2 GR5
2
802-249C
HHCS 1/2-13X4 1/2 GR5 SPTHD
2
802-253C
HHCS 3/8-16X1 3/4 GR2
2
802-254C
HHCS 5/8-11X5 1/2 GR5
4
803-011C
NUT LOCK 5/16-18 PLT
2
803-013C
NUT LOCK 3/8-16 PLT
2
803-019C
NUT LOCK 1/2-13 PLT
12
803-020C
NUT HEX 1/2-13 PLT
2
803-024C
NUT LOCK 5/8-11 PLT
4
803-036C
NUT HEX JAM 1/2-13 PLT
12
804-015C
WASHER LOCK SPRING 1/2 PLT
12
804-017C
WASHER FLAT 1/2 USS PLT
4
804-029C
WASHER FLAT 1 SAE
4
805-058C
PIN COTTER 3/16 X 2
2
810-205C
CYL 2X20X1.12 ROD (TIE) 1 PIN
2
818-229C
DECAL AMBER REFLECTOR
4
818-682C
DECAL WARNING PINCH/CRUSH
2
113-568H
MARKER TRANSPORT MOUNT
2
113-677H
20 BM MARKER TRANSPORT CARRIER
8
800-035C
CABLE TIE 28 LONG
4
802-335C
HHCS 5/8-11X6 1/2 GR5
20
803-020C
NUT HEX 1/2-13 PLT
8
803-021C
NUT HEX 5/8-11 PLT
4
803-036C
NUT HEX JAM 1/2-13 PLT
20
804-015C
WASHER LOCK SPRING 1/2 PLT
8
804-017C
WASHER FLAT 1/2 USS PLT
8
804-021C
WASHER FLAT 5/8 SAE PLT
8
804-022C
WASHER LOCK SPRING 5/8 PLT
Qty.
Part No.
Part Description
