Appendix
Great Plains Manufacturing, Inc.
15
05/05/2011
151-181M
Part Lists
New Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
Quantities are units (“ea”).
Kit Contents
124-051A
806-1006 LIFT ASSIST MOUNT ASSY
Callout
Quantity
Part Number
Part Description
12
1
151-171H
LIFT ASSIST REAR PVT MNT
13
1
151-172H
LIFT ASSIST BOLT ON MOUNT
14
1
151-173H
LIFT ASSIST LWR PARALLEL ARM
15
1
151-179H
LIFT ASSIST FRAME MNT WLDMNT
16
1
151-180H
LIFT ASSIST MOUNT CLAMP WLDMNT
17
1
151-184H
1006 LIFT ASSIST CASTER ARM
18
1
151-381D
LIFT ASSIST AXLE PIVOT PIN
19
2
151-384D
LIFT ASSIST MOUNT CLAMP SPACER
20
2
161-056D
CASTER SPACER
21
1
161-107H
NTA35 WING EYEBOLT WELDMENT
22
1
196-473H
CYL LOCK CHANNEL 1 1/2X12 3
23
4
196-654D
40P CASTER INNER PIVOT TUBE
24
1
402-172H
16R PARALLEL ARM WLDMNT
25
1
500-064D
WASHER - SAFETY CHAIN SA
26
1
800-001C
GREASE ZERK STRAIGHT 1/4-28
27
8
802-053C
HHCS 5/8-11X1 3/4 GR5
28
10
802-055C
HHCS 5/8-11X2 GR5
29
8
802-057C
HHCS 5/8-11X2 1/4 GR5
30
1
802-060C
HHCS 5/8-11X4 GR5
31
4
802-728C
HHCS 1-8X18 GR5
32
26
803-021C
NUT HEX 5/8-11 PLT
33
1
803-024C
NUT LOCK 5/8-11 PLT
34
5
803-031C
NUT HEX 1-8 PLT
35
2
803-034C
NUT HEX 1 1/4-7 PLT
36
26
804-022C
WASHER LOCK SPRING 5/8 PLT
37
5
804-027C
WASHER LOCK SPRING 1 PLT
38
5
804-029C
WASHER FLAT 1 SAE
39
1
804-030C
WASHER LOCK 1 1/4 SPRING PL
40
8
804-195C
WASHER FLAT 1.31ODX.65IDX.188T
41
1
805-001C
PIN 3/8 X 3 USABLE LW/PIN
42
1
805-104C
PIN COTTER 3/16 X 1 1/2 PLT
43
1
805-159C
PIN CLEVIS 1 X 3 1/8 GR5 PL
44
1
810-316C
CYL 3.5X12X1.25 ROD (TIE RO
45
1
810-442C
MW STOP BUSH SET 1 1/4 SBS1
46
1
811-065C
EL 9/16MJIC 9/16MORB
47
1
811-722C
BREATHER PLUG 9/16-18 MORB
48
1
818-349C
DECAL GREASE 10 HRS LH
49
2
838-057C
DECAL WARNING GEN TRANSP LO
50
2
838-266C
DECAL REFLECTOR RED 1 1/2X9
51
2
838-267C
DECAL REFLECTR DAYTIME 1 1/
52
2
848-339C
DECAL CAUTION LIFT ASSIS
53
1
890-005C
BUSHING CYL 1 1/4 X 1 X 1
