Great Plains Vantage II Fertilizer Coulters User Manual
Page 23
4/26/2006
204-310M
21
Parts
1.
204-365K
31 1/2 EXTENSION BRACKET
2.
204-430S
9 1/2 EXTENSION BUNDLE
3.
204-038K
EXT. BRKT X 10
4.
204-039K
EXT. BRKT 3 DIA. BAR
5.
204-031K
FRONT BAR REINFORCEMENT BRKT
6.
204-082H
EXTENSION BRACKET 31 9/16 JD
7.
204-023D
SPACER PLT 7 TO 2 1/2 SQ 9 1/2
8.
204-044H
10 EXT. BRKT
9.
204-058H
EXT. BRKT. DRY FERT 3 DIA
10.
204-029H
FRONT BAR BRKT 18
11.
204-033D
FRONT BAR-BACK STRAP
12.
802-105C
HHCS 5/8-11X9 GR5
13.
802-260C
HHCS 1/2-13X7 GR5
14.
802-053C
HHCS 5/8-11X1 3/4 GR5
15.
806-010C
U-BOLT 1/2-13 X 2 1/2 X 3 1/2
16.
806-055C
U-BOLT 3/4-10 X 7 1/32 X 6 1/2
17.
806-050C
U-BOLT 3/4-10 X 7 X 8 1/2
18.
804-015C
WASHER LOCK SPRING 1/2 PLT
19.
804-022C
WASHER LOCK SPRING 5/8 PLT
20.
804-023C
WASHER LOCK SPRING 3/4 PLT
21.
803-020C
NUT HEX 1/2-13 PLT
22.
803-021C
NUT HEX 5/8-11 PLT
23.
803-027C
NUT HEX 3/4-10 PLT
24.
804-017C
WASHER FLAT 1/2 USS PLT
Ref.
Part No.
Description
