Great Plains Mfg., Inc. Table of Contents
6/30/2008 Verti-Till VT5300-VT9225 Finishing Attachments 596-156M
1
Table of Contents
Using This Manual ............................................. 2
Introduction ........................................................ 2
Section 1 Safety Rules ........................................ 3
General Operation & Repair ......................... 3
Transporting ................................................. 3
Safety Decals ................................................ 3
Section 2 Assembly & Set-Up ............................ 4
Ridge Splitter Assembly ............................... 4
Rolling Harrow Assembly ............................ 5
Seedbed Conditioner to Verti-Till
Attachment .............................................. 6
Section 3 Operating Instructions ...................... 8
Prior to Going to the Field ............................ 8
General Operating Instructions and
In-Field Adjustments ............................... 8
Section 4 Maintenance & Lubrication ............. 9
General Maintenance .................................... 9
Lubrication ................................................... 9
Section 5 Parts & Hydraulics............................. 10
Ridge Splitter ................................................ 10
Rolling Harrow ............................................. 12
Seedbed Conditioner Frame ......................... 14
Seedbed Conditioner Baskets
(S/N 1079MM-) ............................................ 16
Seedbed Conditioner Baskets
(S/N 1080MM-) ............................................ 18
Seedbed Conditioner Hydraulics .................. 20
Seedbed Conditioner Transport .................... 22
Seedbed Conditioner Decals ........................ 24
Section 6 Machine Layouts ............................... 26
VT5300 Ridge Splitter ................................. 26
VT7300 Ridge Splitter ................................. 27
VT5300 & VT7225 Rolling Harrow ............ 28
VT7300 & VT9225 Rolling Harrow ............ 29
VT5300 Ridge Splitter & Rolling Harrow ... 30
VT7300 Ridge Splitter & Rolling Harrow ... 31
VT5300 & VT7225 Seedbed Conditioner ... 32
VT7300 & VT9225 Seedbed Conditioner ... 33
VT5300 Ridge Splitter & Seedbed
Conditioner .............................................. 34
VT7300 Ridge Splitter & Seedbed
Conditioner .............................................. 35
Appendix ............................................................. 36
Torque Values for Common Bolt Sizes ....... 36
Tire Inflation Chart ...................................... 36
