4.

Find the chart for your implement or row spacing.
Charts begin on page 36.
Example: planter is model YP625TD12TR110

5.

Choose the speed (kph) column that is closest to the
planned field speed.
Example: field speed planned is 9.6 kph (use 10.5)

6.

Find the fertilizer rate closest to your corrected or
target rate.
Example: density corrected rate is 137.5 kg/ha (use
136)

7.

In the Transmission columns to the left, find the
DRIVING and DRIVEN sprocket tooth counts
required for the chosen chart rate.

Refer to Figure 15
8.

Inspect the current DRIVING

and DRIVEN

transmission sprockets. It is likely that one or both
need to be changed. If no sprockets need to be
changed, continue at “Dry Fertilizer Rate Check
on page 35.

9.

Loosen the bolt at the idler plate

. Rotate the idler

plate to relax chain tension. Lift the chain of the
DRIVING and/or DRIVEN sprockets that need to be
exchanged.

10. Remove the pins from any sprocket that needs to be

changed, and from the storage tree

.

11. Exchange sprockets between shafts and tree as

needed to match the chart values.

12. Re-engage the idler plate for 1.8 mm chain slack

(see Operator manual for information on chain slack
and chain orientation). Tighten the bolt of the idler
plate.

Import As: /files/iso/text/31500/31824B.eps

YP625TD12TR110

Dry Fertilizer Rate

YP625PD18TP110

110 cm

YP625TD18TP110

Twin-Row, Triple-Row

Transmission

Dry Fertilizer Rates

Transmissio

Sprocket Tooth Count

8.0 kph

9.0 kph 10.5 kph

Sprocket Tooth C

Driving

Driven

kg/ha

kg/ha

kg/ha

Driving

Dri

15

44

88

88

88

24

2

15

41

95

95

94

23

2

17

44

100

100

100

24

2

17

41

107

107

107

23

1

19

44

112

111

111

24

1

19

41

120

119

119

32

2

15

32

121

121

120

32

2

21

44

123

123

122

32

2

21

41

132

132

131

32

1

23

44

135

134

134

41

2

17

32

137

136

136

41

2

24

44

140

140

139

44

2

23

41

144

144

143

32

1

24

41

150

150

149

44

2

19

32

152

152

151

41

2

21

32

168

168

167

44

2

23

32

184

183

182

32

1

24

32

191

191

190

41

1

19

24

202

201

200

44

1

4

5

6

7

Null4:

Sample Char

t Only:

Consult pages 36-

37

for fi

eld oper

ations

.

Null4:

Figure 16

Fertilizer Transmission

31871

DRIVING

DRIVEN

c

b

a

d

a

b

c

d
