Great Plains Manufacturing, Inc.

Table of Contents

Sprocket Indexing (Stagger)

31

09/29/2011

Table of Contents

401-754B

110cm Triple Row Sprocket Indexing (cont.)

Note: This is NOT a seed rate chart.

This is a chart for staggering seed spacing
between rows of a twin-row planter.

Null4.aac:

MetaData: End of Sprocket Indexing (Stagger).

Verify sprocket tooth position with the top length of chain taut.

110cm Triple Row

Set front meter to tooth “1”.

Page 2 of 2

Set rear meter to indicated Initial tooth number.
Advance or Retard to adjust - see instructions in Seed Rate Manual.

These Columns are for Fine Adjustment Only

Population

Initial Rear

20% Rear Seed Drop Adjust

40% Rear Seed Drop Adjust

Seeds/ha

Tooth Number

Retard

Advance

Retard

Advance

79600

9

10

6

4

3

80880

17

14

1

4

18

82160

17

14

2

11

18

83450

5

14

2

8

18

84730

5

18

5

8

14

86020

2

18

17

15

14

87300

1

18

17

12

14

88580

1

3

9

12

14

89870

6

3

9

19

10

91150

6

3

13

19

10

92440

10

7

13

16

10

93720

10

7

13

4

6

95000

10

7

9

4

6

96290

14

11

17

4

1

97570

14

11

17

8

2

98850

14

11

5

8

2

100140

18

11

2

8

5

101420

18

15

2

12

17

102710

18

15

1

12

17

103990

3

15

1

12

9

105270

3

19

6

16

9

106560

3

19

6

16

13

107840

7

19

10

16

13

109120

7

4

10

16

13

110410

7

4

10

16

9

111690

11

4

14

16

17

112980

11

8

14

16

17

114260

11

8

14

16

5

115540

15

8

18

16

2

31823D

Air-Pro

®

Meter Stagger Timing Chart
