Coulter Spring
Refer to Figure 14
41. The coulter springs are preset at the factory to
between 9 7/8” to 10”. This is measured from the inside
surface of the coulter spring washer to the inside sur-
face of the coulter bushing.
Note: Adjusting the spring below 9 7/8” could cause prema-
ture part failure and void the warranty.
Berm Conditioner
Refer to Figure 15
42. The berm conditioner may be adjusted pulling up on
handle sliding to a different notch.
43. For the deepest setting, move handle clear forward.
For shallower, move handle towards rear.
Figure 14
Coulter Spring Adjustment
42792
Figure 15
Berm Conditioner Adjustment
41864
