Great Plains 24F Assembly Instructions User Manual
Page 5
118-073M
4/5/2006
Great Plains Mfg., Inc.
5
Installation Instructions
118-071A 20P/24P/25P Weight Bracket Kit
Your kit includes:
1
118-069H
WEIGHT BRACKET WELDMENT-LH
1
118-070H
WEIGHT BRACKET WELDMENT-RH
2
197-062D
WEIGHT BRACKET ADJ LEG
4
802-057C
HHCS 5/8-11 X 2 1/4 GR5
4
803-021C
NUT HEX 5/8-11 PLT
8
803-027C
NUT HEX 3/4-10 PLT
4
804-019C
WASHER FLAT 5/8 USS PLT
4
804-022C
WASHER LOCK SPRING 5/8 PLT
8
804-023C
WASHER LOCK SPRING 3/4 PLT
2
806-089C
U-BOLT 3/4-10 X 6 1/16 X 9
2
806-093C
U-BOLT 3/4-10 X 6 1/32 X 7 3/4
1
118-073M
MANUAL WEIGHT BRACKET
Qty.
Part No.
Part Description
118-072A 20F and 24F Weight Bracket Kit
Your kit includes:
2
118-068H
WEIGHT BRACKET WELDMENT
2
197-062D
WEIGHT BRACKET ADJ LEG
4
802-057C
HHCS 5/8-11 X 2 1/4 GR5
4
803-021C
NUT HEX 5/8-11 PLT
8
803-027C
NUT HEX 3/4-10 PLT
4
804-019C
WASHER FLAT 5/8 USS PLT
4
804-022C
WASHER LOCK SPRING 5/8 PLT
8
804-023C
WASHER LOCK SPRING 3/4 PLT
4
806-203C
U-BOLT 3/4-10 X 5 1/32 X 4
1
118-073M
MANUAL WEIGHT BRACKET
Qty.
Part No.
Part Description
