Great Plains 2SNT30 Assembly Instructions User Manual
Page 3
4/9/04
1-1
113-395M
TABLE OF CONTENTS
Introduction ----------------------------------------- 1-0
Table Of Contents -------------------------------- 1-1
Nut & Bolt Torquing Chart ---------------------- 1-1
Safety Rules ---------------------------------------- 1-2
Marker Installation Instructions ---------------- 1-3
Single Marker Hydraulics ------------------------ 1-8
Dual Marker Hydraulics -------------------------1-10
Marker Adjustments------------------------------1-12
Marker Maintenance & Lubrication-----------1-13
Marker Transportation ---------------------------1-13
Bleeding Of The Hydraulics --------------------1-14
Trouble Shooting----------------------------------1-15
Warranty -------------------------------------------1-16
Parts Book Table Of Contents-----------------1-18
NUT & BOLT TORQUING CHART
This chart is based on torque requirements in foot pounds for grade 5, coarse threaded bolts.
BOLT MINIMUM MAXIMUM BOLT MINIMUM MAXIMUM
DIAMETER TORQUE TORQUE DIAMETER TORQUE TORQUE
1/4”
9
11
3/4”
270
324
5/16”
17
20
7/8”
400
480
3/8”
35
42
1"
580
696
7/16”
54
64
1 1/8”
800
880
1/2”
80
96
1 1/4”
1120
1240
9/16”
110
132
1 3/8”
1460
1680
5/8”
150
180
1 1/2”
1940
2200
NOTE: Torque requirements listed above do not apply to self-locking nuts. For self-locking nuts increase the torque
requirements listed above by 15%.
