Great Plains 2SNT30 Assembly Instructions - Manual (Page 2)

4/9/04 1-0
113-395M
Your Great Plains 2-Section No-Till Flat Fold Marker is designed to give you many years of depend-
able service. This manual has been prepared to instruct you in the safe and efficient operation of
this machine. Read and study it thoroughly. Follow all instructions and service procedures carefully.
The parts on your 2-Section No-Till Flat Fold Marker have been specially designed and should only
be replaced with genuine Great Plains parts. Therefore; should your drill require replacements parts,
purchase them from your Great Plains Dealer.
The Great Plains 2-Section No-Till Flat Fold Marker is an option made available to fit the Great
Plains 2 Section Folding No-Till Drill manufactured after February of 1993.
The marker features as standard equipment a notched 16" disk with depth band, mounted on
("Timken") tapered roller bearings. The disk assembly can be angled to vary the aggressiveness of
the cut, and can be mounted to throw dirt in or out. The marker is available in two lengths, capable
of marking to the tractor's center line on either a 24' or 30' drill. The marker body is split into 4 sec-
tions with 3 hinges that allow the marker to be "flat folded" back upon itself for low profile storage.
Four different assemblies have been created to allow your dealer to order the marker needed to fit
your application and your drill. The part numbers and descriptions for these assemblies are as fol-
lows:
113-383A 24' NO-TILL LH FLAT FOLD MARKER (single marker left hand mount only)
113-384A 24' NO-TILL DUAL FLAT FOLD MARKER (dual markers left and right)
113-385A 30' NO-TILL LH FLAT FOLD MARKER (single marker left hand mount only)
113-386A 30' NO-TILL DUAL FLAT FOLD MARKER (dual markers left and right)
Each "A" bundle contains all the marker parts, hardware, hydraulic hoses, hydraulic fittings and
valves that you will need to install the marker on your 2 Section No-Till Drill.
The following signal symbol and words should be clearly understood! When seen in this manual or
on your equipment, this symbol and words will alert you to the seriousness of a situation. They
should not be ignored or taken lightly.
!
The SAFETY ALERT SYMBOL indicates that there is a potential hazard to personal safety
involved and extra safety precautions must be taken. When you see this symbol, be alert and care-
fully read the message that follows it. In addition to design and configuration of equipment; hazard
control and accident prevention are dependent upon the awareness, concern, prudence and proper
training of personnel involved in the operation, transport, maintenance and storage of equipment.
DANGER:
Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury This signal word is limited to the most extreme situations.
WARNING:
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury. It may also be used to alert against unsafe practices.
Thank you for buying a Great Plains 2-Section No-Till Flat Fold Marker.
INTRODUCTION
