Great Plains Mfg., Inc. Front Parts Installation Instructions 13
2014-06-16 Front Parts 118-598M
Quantities are units (“ea”).
Existing Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
Abbreviations
71 808-143C SPKT 40B12 7/8 HEX BORE W/SS
72 808-167C SPKT 40B14 X 3/4 HEX BORE
73 808-194C SPKT 40B22 7/8 HEX BORE & SS
74 817-025C NO. 40 12T IDLER SPKT.
75 822-032C FLANGETTE 52 MST
76 822-041C FLANGETTE 47 MST
77 822-119C BRG 7/8HEXX2.05OD SPH
78 822-128C BRG INS 3/4HEXX1.85OD SPH
Call
out
Part
Number
Part Description
11 1 1/2 x 1 Long Bolt
11 2 1/2 Lock Washer
11 3 1/2 Hex Nut
11
Callout
Part
Number
Part Description
3PT 3 Point HHCS Hex Head Cap Screw
ASY Assembly IN Inch/Inches
DBL Double LG Long
EWNT End-Wheel No-Till PLT Plated
FT Foot/Feet SPRG Spring
GR5 Grade 5 USS United States (heavy duty) Standard
HEX Hexagonal x by
