Appendix Front Page Part Lists Great Plains Manufacturing, Inc. 7
08/21/2009 Front Page Part Lists 151-169M
Appendix
Part Lists
New Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual. Quantities are units (“ea”).
Kit Contents
Existing Parts Affected
The following existing parts are involved in the kit instal-
lation. The Disposition column indicates whether the part
is left in place, moved or not re-used. The part call-out numbers in the list matches all Figures
in the installation instructions. The descriptions match
those in your implement Parts manual.
Abbreviations
Callout Quantity Part Number Part Description
11 1 151-169M 1007 CASTER BRACE UPDATE MAN
12 4 151-359D REAR CASTER BRACE PLATE
13 16 802-091C HHCS 1/2-13X1 1/2 GR5
14 16 803-020C NUT HEX 1/2-13 PLT
15 16 804-015C WASHER LOCK SPRING 1/2 PLT
Callout Part No. Part Description Part Disposition
51 119-032D 3-PT STEP RETAINER Removed and re-installed.
52
119-296D
119-303H
142-318D
1006 WALKBOARD
1006 SEED WALKBOARD WELDMENT
3P1006NT FERTILIZER WALKBOARD
Removed and re-installed.
53 802-079C HHCS 3/8-16X1 1/4 GR5 Removed and re-installed.
54 803-014C NUT HEX 3/8-16 PLT Removed and re-installed.
1006 Drill Model Number HHCS Hex Head Cap Screw (Bolt)
1007 Drill Model Number MAN Manual
3P, 3-PT Three Point (hitch) NT No Till
GR5 Grade 5 PLT Plated
HEX Hexagonal X by
