6 Great Plains Manufacturing, Inc. Front Page Part Lists Caster Brace Update
151-169M Front Page Part Lists 08/21/2009
Closeout
Re-Install Walkboard
Refer to Figure 8
27. Position walkboard
, with SMV reflector to rear, so
that one end is just inboard of the retainers .
28. Lift the retainers and slide the walkboard under
them, and a few inches (10cm) past the side of the
frame.
29. At the other side of the drill, lift the retainers at that
end, and slide the walkboard under them. Center the
walkboard between the frame sides.
30. Tighten nuts to torque spec:
31 ft-lbs (42 N-M)
Figure 8
Re-Install Walkboard
28386
54
51
52
52
52
54
