6

8323-8560FCF

Great Plains Manufacturing, Inc.

560-484Q

02/10/2014

Shipping

The Field Cultivator will be shipped pre-assembled as
shown.

• The Field Cultivator will be shipped with shipping

stands that will not need to be returned to Great
Plains.

• Wings will be connected to center frame and un-folded

in field position.

• All hydraulics will be connected and purged.

• Shank mount assemblies will be attached to frames in

proper locations.

• Shank assemblies will be shipped in a box on a pallet.

• Finishing attachments (if equipped), will be pre-

assembled and banded to pallet.

Unloading

Be sure the truck is on level ground, preferably concrete.

Centering componets:
The Field Cultivator is very heavy, be sure and use 2, 8000# fork
trucks to unload machine. Be sure and center fork truck or chains
(overhead hoist) on componets so they won’t slide and cause injury.

Unload Smaller Items First

Unloading the Field Cultivator is a potentially dangerous
operation.

Reduce risk and complications by first unloading

6.

the finishing attachments

7.

the misc. boxes

8.

the Field Cultivator (described in the next section)

Unload Field Cultivator

9.

Place these components well out of the manoeu-
vring area needed for unloading the Field Cultivator.

10. Double-check that all chains and tie-down straps

have been released and stowed.

11. Set parking brake on trailer tractor.

12. On some models you will need to hook the machine

up to a hydraulic source and fold the machine com-
pletely in the transport position before removing from
trailer.

13. Slowly lift the Field Cultivator off trailer bed using two

fork lifts.

14. Stop lifting about 12” above the bed.

15. Have the truck driver slowly pull the trailer straight

out from under the Field Cultivator.

16. Making sure to keep level from front to back and side

to side, slowly lower the Field Cultivator.

17. Lower theField Cultivator down until the shipping

stands are about 12” off ground.

18. Remove shipping stands.

19. Slowly lower Field Cultivator until it resting on the

center transport tires and sweeps.

Unpacking Boxes

Note: Position boxes in area that you can maneuver

components up to machine to assembly.

20. Carefully remove banding from boxes.

21. Carefully remove banding from finishing reels.

22. Locate and identify all componets before assem-

bling.

Assembly and Setup Assistance

To order additional copies od pre-delivery instructions or
operator.s and parts manuals, write to the following
address. Include model numbers in all correspondence.

If you do not understand any part of this manual or have
the assembly or setup questions, assistance is available.
Contact:

Product Support

Great Plains Mfg. Inc., Service Department

PO Box 5060

Salina, KS 67402-5060

(800)255-9215
