9. Appendix
9.1. SPECIFICATIONS
Important: The capacity of the Portable Pit is dependent on the hydraulic power source.
Hydraulic flow or pressure below the nominal requirements will reduce the rated
output.
Wheatheart Manufacturing reserves the right to change specifications without
notice.
CAPACITIES
10” 13"
Unloading Rate 5000 Bu / Hr (175m
3
/hr) 8000 Bu / Hr (280m
3
/hr)
Max Vehicle Weight 100,000 LB GVW (45000kg) 100,000 LB GVW (45000kg)
HYDRAULICS
Hydraulic Flow
Nominal 14 GPM (US) (53 l/min) 14 GPM (US) (53 l/min)
Maximum 16 GPM (US) (60 l/min) 20 GPM (US) (76 l/min)
Hydraulic Pressure Nominal 1500 PSI (10500kPa) 2000 PSI (14000kPa)
Maximum 1800 PSI (12500kPa) 3000 PSI (21000kPa)
ELECTRIC
Electric Motor Size
Nominal 7.5HP(5.6kW) 14HP(10.5kW)
Maximum 10HP(7.5kW) 15HP(11.2kW)
DIMENSIONS
Transport
Length 250” (6350mm) 253" (6426mm)
Width 75”(1905mm) 75”(1905mm)
Height 67”(1702mm) 72" (1829mm)
Operating Length 250”(6350mm) 253" (6426mm)
Width 147”(3734mm) 147”(3734mm)
Height –
Frame
7-1/2”(191mm) 7-1/2”(191mm)
Height –
Belting
13”(330mm) 13”(330mm)
Ramp Length 48”(1219mm) 48”(1219mm)
Width 30”(762mm) 30”(762mm)
Centre to
Centre
78”(1981mm) 78”(1981mm)
Discharge Clearance 26”(660mm) 24 3/4”(629mm)
Under-Vehicle Clearance 7-1/2”(191mm) 7-1/2”(191mm)
TIRES
Type
P225/70R15 P225/70R15
Inflation Pressure Refer to Rating on Tire Refer to Rating on Tire
HOPPERS
Centre
43” x 47”(1092x1194mm) 43” x 47”(1092x1194mm)
Side 30” x 35-3/4”(762x908mm) 30” x 35-3/4”(762x908mm)
WEIGHT
Hitch Tongue Weight
1040 LB (475kg) 1230 LB (558kg)
Total Weight 2900 LB (1315kg) 3000 LB (1360kg)
