W HEATHEART - SA A UGERS 8. A PPENDIX
SA 1061, 1071, 1081, 1091, 1371, 1381, 1391 8.1. S PECIFICATIONS
30582 R7 39
8. Appendix
8.1. SPECIFICATIONS
Important: Wheatheart Manufacturing reserves the right to change specifications without
notice.
Table 8.1
1061 1071 1081 1091 1371 1381 1391
CAPACITy
Unloading Rate 5400 - 6000 Bu/Hr 8700 - 9600 Bu/Hr
DIMENSIONS
Tube Size 10” 10” 10” 10” 13” 13” 13”
Transport
Length 63’5” 73’6” - - - - -
Width 11’ 11’ 11’8” / 15’ 11’8” / 15’ 11’8” / 15’ 11’8” / 15’ 11’8” / 15’
Height 12’11” 12’11” 13’6” 13’6” 12’1” 11’8” 12’4”
Discharge
Clearance Min 11’ 11’ 11’6” 11’7” 9’9” 9’3” 9’11”
Max 41’1” 47’ 52’6” 58’6” 49’ 53’9” 61’3”
Reach to
Wheels Min 23’5” 26’10” 29’2” 35’5” 26’9” 29’1” 30’1”
Max 29’6” 34’2” 39’3” 45’ 35’9” 42’ 45’2”
TIRES
Type Type 15” Bias Ply 16” Bias Ply
Inflation Pressure 18 – 24 psi
Hubs 6 Bolt Automotive Type
WEIGHT
Total Weight 3100 lb 3410 lb 3980 lb 5010 lb 4915 lb 5550 lb
6745 lb
est.
PTO DRIVE
Power Requirements 60 HP 65 HP 80 HP 90 HP 100 HP 120 HP 140 HP
PTO Speed 540 rpm
PTO Shaft 14R Constant Velocity w/ Shear 35R
OTHER
Hitch Jack 2000 lb Side Winder
