W HEATHEART - SA A UGERS 3. T RANSPORT & P LACEMENT
SA 1061, 1071, 1081, 1091, 1371, 1381, 1391 3.2. P LACEMENT P ROCEDURE
30582 R7 17
b. Ensure there is no more slack in the chain than required for turning.
c. When not in use, store the safety chain in a clean, dry place. Replace the
safety chain if one or more links or end fittings are broken, stretched, or
otherwise damaged or deformed (Figure 3.3).
3.2. PLACEMENT PROCEDURE
Important: Wheels must be free to move when raising or lowering the auger.
1. Disconnect PTO driveline from tractor.
2. Position towing hitch and secure (Figure 3.5).
Important: Always use a safety chain when transporting the
auger.
3. Extend wheels (1081, 1091, and 13” models
only) as shown in Figure 3.4
4. Check that hydraulic hoses and connections are
undamaged and free from leaks.
Figure 3.5
Note: Replacement hose and hose ends must have a minimum strength of 2500 psi
(17200 kPa) working pressure.
5. Place the auger on a firm, level surface.
WARNING
Maximum transport speed:
Do not transport faster than 15 mph

(24 km/h), or faster than road conditions
allow.
A weight imbalance between the towing
vehicle and the machine could reduce your
vehicle’s stability, handling, and braking
ability, and lead to an upset or collision.
Figure 3.4 Wheel Extended
