7
The pulse signal on the connector marked “Output” provides a sharp
leading edge for reliable and repeatable triggering of the connected
device. This output is capable of driving a hundred feet of coax cable.
Be sure to select the direction (0 to 5 Vdc or 5 to 0 Vdc) of this signal
to provide the required polarity of the leading edge to properly trigger
the connected equipment.
BATTERY DISPOSAL
Prior to disposing of the SPSR-IM, the user must remove the Nickel Metal
Hydride batteries. To do this, remove the four (4) rubber feet on the bottom of
the unit. This will expose four (4) screws that must be removed to dismantle
the bottom case piece, exposing the batteries. Remove the batteries and place
tape over the battery terminals to prevent them from shorting. The batteries
should be sent to a recycling center or returned to the factory. The rest of
the parts may now be disposed of.
NOTE: This product contains Nickel Metal Hydride (NiMH) batteries.
Replace only with the same type of battery – Rechargeable NiMH.
TABLE OF CONTENTS TABLE OF CONTENTS
INTRODUCTION ...................................................................1
COMPONENT SPECIFICATIONS ........................................1
SPSR-IM Interface Module ............................................1
ROS-P Remote Optical Sensor.......................................3
FUNCTIONS AND OPERATION ...........................................4
SPSR Interface Module ..................................................4
Connections ..............................................................4
Controls ....................................................................4
LED Indication ..........................................................5
Recharging the Batteries ..........................................5
SPSR-115/230 Series - SPSR-IM with ROS-P ..............6
ROS-P ......................................................................6
Operating the SPSR as a triggering source .............6
BATTERY DISPOSAL ...........................................................7
SENSORS / OPTIONS AND ACCESSORIES ......................8
