7
A recommended professional approach to setting up a conference room utilizing the
CHATAttach accessory is to drill holes near where the CHAT devices will be placed, route
the cabling through the holes and secure them underneath the conference table.
CHATAttach Working Modes
The following table outlines the CHATAttach working modes.
Mode # Mode Code description Condition
1
Solid Red LED on both CHAT
devices. Both CHAT devices are in
MUTE mode.
Normal
2 Solid Blue LED on both
CHAT devices Both CHAT devices are in
UNMUTE mode.
Normal
3
Single Blue Volume light on
both CHAT devices.
No PC attached. Both
CHAT devices are in STAND-
BY mode and will WAKE-UP
when a PC is reattached
to a device. All previous
CHAT device settings will be
reinstated.
Normal
