PARTS lIST
Part
Description
qty.
1
Left Crankcase
1
2
Right Crankcase
2
3
Bearing (6004)
2
4
Hole Circlip (#42)
1
5
Oil Seal (20 x 30 x 7)
2
6
Pin (10 x 7 x 14)
2
7
Stud (AM6 x 50)
2
8
Flange Nut (M6)
4
9
Flange Bolt (M6 x 45)
4
10
Stud (AM6 x 100)
2
11
Oil Seal (6 x 12 x 7)
1
12
Governor Shaft
1
13
Washer (6 x 10)
2
14
Governor Fork
1
15
Cross Round Head Bolt (M3 x 8)
2
16
Spring Washer (#3)
2
17
Governor Arm
1
18
Collar Bushing
1
19
Weight Comp
1
20
Flange Bolt (M6 x 16)
4
21
Crankshaft Assy.
1
22
Circlip
2
23
Piston Pin
1
24
Roller Bearing (14 x 10 x 14)
1
25
Piston
1
26
Second Piston Ring
1
27
First Piston Ring
1
28
Cylinder Gasket
1
29
Cylinder
1
30
Cylinder Cap Gasket
1
31
Cylinder Cap
1
32
Flange Bolt (M6 x 105)
2
33
Nut (M6 x 18)
2
34
Cylinder Cap Cover
1
35
Flange Bolt (M6 x 12)
10
36
Ignition Coil Assy.
1
37
Clamp
1
38
Spring Washer (#6)
7
39
Cross Round Head Bolt (M6 x 16)
2
40
Flywheel
1
41
Flange Nut (M10 x 1.25)
1
Part
Description
qty.
42
Recoil Starter Assy.
1
43
Intake Valve Gasket
1
44
Intake Valve Assy.
1
45
Flange Bolt (M6 x 20)
4
46
Stud (AM6 x 60)
2
47
Intake Gasket
1
48
Carburetor
1
49
Carburetor Gasket (B)
1
50
Carburetor Gasket (A)
1
51
Supporting Plate
1
52
Compression Spring
1
53
Cross Round Head Bolt (M6 x 40)
1
54
Rod Link
1
55
Tension Spring
1
56
Governor Spring
1
57
Control Panel
1
58
Capacitor
1
59
Self Tapping Screw (ST4.2 x 13)
1
60
Alternator Stator
1
61
Alternator Rotor
1
62
Flange Bolt (M8 x 156)
1
63
Rear Cover
1
64
Flange Bolt (M6 x 80)
3
65
Washer (#6)
3
66
Flange Bolt (M6 x 10)
2
67
Muffler
1
68
Muffler Gasket
1
69
Flange Bolt (M6 x 16)
2
70
CDI Winding
1
71
Spark Plug
1
72
Absorber
4
73
Fuel Tank
1
74
Strainer
1
75
Fuel Cup
1
76
Fuel Tank Cap
1
77
Handle
1
78
Cross Round Head Bolt (M6 x 30)
1
79
Washer (#6)
2
80
Fuel Switch
1
81
Rubber
1
82
Choke Lever
1
