Page 10 For technical questions, please call 1-800-444-3353. SKU 66619
FIGURE c
FUEl
TANK
cAP
(76)
STRAINER
(74)
3. Remove the Fuel Tank Cap (76) and
check the fuel level.
(See Figure c.)
WARNING! To PREvENT
SERIoUS INjURY FRoM FIRE:
Fill the Fuel Tank (73) in a well-
ventilated area away from ignition
sources. Do not smoke.
To fill the Fuel Tank (73), first wipe off the
4.
Fuel Tank Cap (76) and the surrounding
area.
(See Figure c.)
Unscrew, and remove the Fuel Tank Cap
5.
(76). (See Figure c.)
Remove the Strainer (74) and remove 6.
any dirt and debris. Then replace the
Strainer. (See Figure c.)
Fill the Fuel Tank (73) to about 1 inch 7.
under the fill neck of the Tank with the
pre-mixed unleaded gasoline/2-cycle oil
mixture.
Then replace the Fuel Tank Cap (76).
8.
(See Figure c.)
Start Procedure:
before starting the Engine:
Inspect the Generator and Engine. a.
Fill the Fuel Tank (73) with the b.
proper amount and type of
unleaded gasoline and 2-cycle oil.
(See Figures b and c.)
NOTE: Only after the Generator c.
has stabilized and is running
smoothly should an appliance or
tool be plugged into the AC Outlet
of the Generator.
FIGURE D
FUEl
SWITch
(80)
“oPEN”
1. Turn the Engine Fuel Switch (80) to its
“oPEN” position. (See Figure D.)
FIGURE E
“choKE”
“RUN”
choKE
lEvER
(82)
2. Turn the Engine Choke Lever (82) to its
“choKE” position. Set the Choke Lever
