Quoizel KY8701IB Kyle User Manual
Package contents, Warnings and cautions, Preparation

PACKAGE CONTENTS
INSTRUCTION SHEET IS KY8701
: -
STYLE NUMBER KY8701IB
:
Revised 11 28-2008
-
1 OF 2
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,
.
.
.
Part
A
E
C
G
B
F
D
H
Description
Crossbar
Green Ground Screw
Mounting Screws
Lock Washer
Hex Nut
Mounting Ball
Shade
Quantity
1pc
2pcs
2pcs
1pc
2pcs
2pcs
1pc
A
B
C
D
E
F
1pc
Fixture Body
G
H
WARNINGS AND CAUTIONS
!
PREPARATION
WARNING:
● Before beginning the installation, turn off electricity at the circuit breaker box or the main fuse box by
switching off the circuit breaker or removing the fuse.
CAUTIONS:
● These instructions are provided for your safety. It is very important that they are read completely before the
installation of your fixture. We strongly recommend that a professional electrician install the fixture.
● Disconnect fixture from the power source before replacing the bulb(s), making sure the bulb(s) had sufficient
time to cool down. DO NOT subject the lamp to any shock while lit as shattering of lamp may result.
Before beginning installation of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement part.
● Estimated Assembly Time: 15
30 minutes
● Tools Required for Assembly(not included): Flathead Screwdriver Phillips Screwdriver, Pliers, Electrical
Tape, Wire Cutters, Safety Glasses &1,100 Watt, Type - A Medium Base Bulb.
● Helpful Tools(not included): Wire Strippers.
●
-
,
ASSEMBLY INSTRUCTIONS
STEP 1:
a Screw the Mounting Screws into the Crossbar
place the
Lock Washers over the Mounting Screws and thread the
Hex Nuts onto the Mounting Screws as shown
Secure the
position of the Mounting Screws by tightening the Hex Nuts
against the Crossbar
b
Secure the Crossbar to the Outlet Box with Outlet Box
Screws
.
,
.
.
.
.
Outlet Box
Crossbar
Mounting Screw
Hex Nut
Outlet Box Screw
Lock Washer
