Quoizel TF1697TWT Tiffany - Manual (Page 4)

4of4
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
Assembly Instruction Sheet #IS-TF1697TWT
For Style TF1697TWT
August2013
STEP 2 Install Stem
-
A. Thread the Short Nipple end of Stem (A) into the
Coupling on the top center of the Socket Assembly (B).
Hand tighten until snug.
Figure 2
Stem
Coupling
Figure 3
STEP 3 Install Shade
-
A. Place the Flat Washer (F) and Shade (E) over the Stem
(A). Secure by threading the Finial (D) onto Stem (A).
Hand tighten until snug.
Stem
Shade
Flat Washer
Finial
STEP 4
- Install Bulb
A. This fixture uses standard bulb with medium base .
Maximum 60 watts.
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to use. Enjoy!
Figure 4
Bulb
Socket
Socket Assembly
