Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700

or visit us on-line at www.quoizel.com

2013 QuoizelInc.

Assembly Instruction Sheet #IS-TF1697TWT

For Style TF1697TWT

August2013

Part

Description

Quantity

A

1 pc.

1 pc.

1 pc.

1 pc.

B

C

D

Base

Stem 5.5”L

Package Contents

A

B

C

D

Finial

1 pc.

E

E

Flat Washer

F

1 pc.

F

Shade

Socket Assembly

STEP 1

Assemble Socket Assembly to Base

-

A. Thread Socket Assembly (B) onto Base (C) as shown.

Hand tighten until snug.

Figure 1

Socket Assembly

Base
