Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
4of4
Assembly Instruction Sheet #IS-Q1507T
For Style Q1507T
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
STEP 2 attach Shade to Fixture Body
-
A. Place Tube (D) , Check Ring (C) and Shade (B) over the
Center Stem (E). Secure by thread Finial (A) onto the
Center Stem (E), hand tighten until snug.
Figure 3
Shade
Check Ring
Tube
2012 QuoizelInc.
Center Stem
Spider
Finial
STEP 3
- Install Bulb
A. This fixture uses standard bulb with standard screw
base . Maximum 100 watts.
B. Insert bulb and screw snugly into place.
Your lamp is now assembled and ready to use.
Enjoy!
Figure 3
Bulb
Socket
