Quoizel Q1507T Quoizel Portable Lamp User Manual
Page 3
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of4
Assembly Instruction Sheet #IS-Q1507T
For Style Q1507T
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,
.
.
.
STEP 1
attach Center Stem to Fixture Body
-
A. Thread Hex Nut (F) onto one end of Center Stem(E).
B. Thread the end of Center Stem (E) with Hex Nut (F) into
Hex Coupling on the top of Fixture Body (G). Hand
tighten until snug.
Figure 1
2012 QuoizelInc.
Fixture Body
Hex Nut
Center Stem
Hex Coupling
October2012
