6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
5of5
Assembly Instruction Sheet #IS-QF1213SHO
For Style QF1213SHO
STEP 5
- Attach Shade to Socket
A. Place the Shade (G) over the Socket and secure with
the Socket Collar (H). Hand tighten until snug.
Figure 6
October2011
Socket
Socket
Socket
Collar
STEP 6 Install Bulb
-
A. This fixture uses standard bulb with a standard screw base.
Maximum 100 watts.
B. Insert bulb and screw properly into place.
Your lamp semi-flush fixture is now assembled and ready to
use. Enjoy!
Socket
Bulb
Figure 7
