Quoizel QF1213SHO Quoizel Fixture User Manual

Page 2

background image

2of5

QF1213SHO

1

2

PART NUMBER

NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2

"

REPLACEMENT PART DESCRIPTION

REQ.

NO.

FINISH: HARBOR BRONZE

9478KIT

G2481SH

MTG HARDWARE HARBOR BRONZE 4"D

SHADE OPAL ETCHED GLASS 5"D

1

1

1

GND

2.4mm
13Ga

QUOIZEL

R

(4)100W A19

Medium Base Bulbs

(Not Supplied)

6" Sq.

11"

5"

5" Sq.

19" Sq.

2
