Installation instructions, Step 5 – Quoizel NA1616BN New England User Manual
Page 3
INSTALLATION INSTRUCTIONS
3 OF 3
STYLE NUMBER NA1616BN
:
.
.
.
Your installation is completed now
Restore electricity
Retain this sheet for future reference
Shade
Ceiling Canopy
STEP 5
:
a
Place the Shade inside of the Shade Holder.
b
Lift the Shade Holder with Shade upwards over the
sockets. Place the Pins on the bottom of the Ceiling
Canopy into the holes on the Decorative Parts. Please
make sure the No. 1 Pin and No. 1 Decorative Part are put
together.
.
.
b
Thread the Lock Screw into the mounting hole on the side
of the Decorative Part and hand-tighten until snug to
secure the Shade Holder with the Shade.
.
1
1
Pin
Shade Holder
Decorative
Part
Lock Screw
