Chicago Electric 14 Industrial Cut-off Saw 68104 - Manual (Page 10)

Page 10 For technical questions, please call 1-800-444-3353. Item 68104
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description Description
1 Bolt M6x14
2 Rubber Foot
3 Bolt M8x12
4 Base
5 Depth Adjustment Base Depth Adjustment Base
6 Depth Nut M8 Depth Nut M8
7 Depth Bolt M8x40 Depth Bolt M8x40
8 Vise Crank
9 Pin 4X20
10 Threaded Rod
11 Quick Release Base
12 Rivet
13 Rod Bushing Rod Bushing
14 Ø20 Retaining Ring Ø20 Retaining Ring
15 Quick Release
16 Angle Guide Angle Guide
17 Bolt M10x25
18 Vise
19 Cotter Pin
20 Vise Pin
21 Lock Ball
22 Lock Pin O-Ring Lock Pin O-Ring
23 Lock Pin Shaft
24 Nut M8
25 Support Block Support Block
26 Lock Pin M8
27 Spring Washer Spring Washer
28 Flat Washer
29 Bolt M8x20
30 Flat Washer
31 Spring Washer Spring Washer
32 Bolt M5x12
Part Description Description
33 Nut M6
34 Hinge Cover Hinge Cover
35 Bolt M5x22
36 Washer
37 Spacing Nut Spacing Nut
38 Nut M5
39 Bolt M4x14
40 Movable Guard
41 Arbor Bolt M10x20
42 Arbor Washer
43 Outer Flange Outer Flange
44 Cut-off Wheel
45 Washer
46 Inner Flange Inner Flange
47 Screw M5x55
48 Stationary Guard Stationary Guard
49 Gearbox Cover
50 Bearing 6203 Bearing 6203
51 Ø40 Binding Ring Ø40 Binding Ring
52 Output Spindle Output Spindle
53 Washer
54 Key Key
55 Gear
56 Ø16 Binding Ring Ø16 Binding Ring
57 Washer
58 Spindle Lock Cover Spindle Lock Cover
59 Screw M4x8
60 Spring Spring
61 Spindle Lock Pin Spindle Lock Pin
62 Spindle Lock Spindle Lock
63 Bearing 6302 Bearing 6302
64 Rotor
Part Description Description
65 Bearing 6200 Bearing 6200
66 Seal Ring Seal Ring
67 Screw M6x70
68 Spring Washer Spring Washer
69 Flat Washer
70 Stator
71 Motor Housing Motor Housing
72 Carbon Brush Hole
73 Carbon Brush
74 Carbon Brush Cover
75 Screw M5x8
76 Intermediate Cover
77 Bearing Back Cover Bearing Back Cover
78 Motor Housing Back Cover Motor Housing Back Cover
79 Toothed Washer
80 Spring Pin 8X40 Spring Pin 8X40
81 Spring Spring
82 Block
83 Pin
84 Screw St3.9x20
85 Screw St3.9x14
86 Left Handle
87 Right Handle Right Handle
88 Trigger Trigger
89 Power Cord Protector
90 Power Cord
91 Power Cord Clamp Power Cord Clamp
92 Wrench
93 Plug Plug
94 Rivet
95 Wheel
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
