Quoizel TVN232DK Tavern - Manual (Page 2)

TVN232DK
2of6
6”
12”
FINISH: WESTERN BRONZE
41” OVERALL HEIGHT
INCLUDES
(4) 6” AND 12” RODS
GND
2.4mm
13Ga
QUOIZEL R
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ. NO.
I1101EC
9006EXDK
9012EXDK
RE U 1910 INCANDESCENT BULB PROD CT
ROD EXT DARKEST BRONZE 6"L X 0.5"D
ROD EXT BRONZE 12"L X 0.5"D DARKEST
8
4
4
1
2
3
3
2
(6)60W
Medium Base Bulbs
(Not Supplied)
10.5”
1”
6.5”
12”
32”
4.5”
1
10.5”
