INSTALLATION INSTRUCTIONS

3 OF 3

STEP 5:

a

Place the Ceiling Canopy over the Mounting Screws and

thread Mounting Balls onto the Mounting Screws to secure
it. Hand tighten until snug.

.

Outlet Box

Mounting Screw

Ceiling
Canopy

Mounting Ball

STEP 7

.

:

a

Install the correct Bulb referring to fixture markings and/or labels for maximum wattage.

Your installation is completed now. Restore electricity. Retain this sheet for future reference.

STEP 6:

a

Place the Shade and the Steel Collar (opened end is

downwards) over the Socket as shown. Secure by
threading the Socket Collar onto the Socket. Hand tighten
until snug.

.

Socket

Shade

Steel Collar

Socket Collar

STYLE NUMBER TF1507VB,TFFS1507VB

:
